Lora Battery Powered 9V Solenoid Control

General Features:
1. You can open and close your hydraulic valves as battery-powered up to 15km.
2. It can perform readings every 5 minutes with the internal battery at certain intervals, and continuously with external and solar panels.
3. It has a 9V-24V 250mA external power supply input.
4. While in battery mode, it checks center information every 5 minutes.
5. There is no data loss in case of turning off and on.
6. The device has Lora modulation and LoraWan protocol with EU-868 Mhz frequency band and 14db output power.
7. It has an external antenna connection.
8. Configuration processes can be performed via the system.
9. Energy status, operating status, and alarm status can be monitored with the LEDs on it.
10. When the device is not sending data, it works in Ultra Low Power mode and does not consume unnecessary energy.

Application Areas:
1. Remote turning on/off
2. Valve opening/closing
3. AMR systems
4. Automation systems
5. Scada systems
6. Remote control systems

Technical Specifications:
1. Frequency Range: 433/490 MHz or 868 / 915 MHz(Customizable:137~1020MHz )
2. Sensitivity up to -139dBm @Lora
3. EU433,CN470-510,CN779-787,EU863-870,US902-928,AU915-928,AS923,KR920-923
4. Maximum output power: 20 dBm
5. 13mA@receiver mode
6. Sleep current <200 nA 7. Data transfer rate: @FSK,1.2-300 Kbps 8. @Lora TM, 0.018-37.5 Kbps 9. Lora TM, FSK, GFSK & OOK Modulation mode 10. Built-in ESD Protection 11. 127 dB Dynamic Range RSSI 12. Packet engine up to 256 bytes with FIFO and CRC 13. Hopping frequency 14. Built-in temperature sensor and low battery indicator 15. Excellent blocking immunity 16. Operating Temperature Range：-40 ~ + 85 °C 17. Low Power Current 4uA 18. Max TX Current 120mA

Box Contents:
1. Lora Battery Powered 9V Solenoid Control
2. RF Antenna 1 piece
3. Extended RF Antenna (optional) 1 piece
4. 3V6 Lithium Battery (Optional) 1 piece
