Automatic Liquid Fertigation System-Smart Agro-Series

In modern agriculture and professional greenhouse farming, precise plant nutrition and yield optimization are critical. Smart Agro-Max provides the ideal nutrient formulation plants need at every growth stage by ensuring precise mixing of nutrient elements into irrigation water with advanced sensor technology and fully automatic control systems.

Smart Agro-Max - Smart Series: Smart Agriculture and Greenhouse Management Systems

Smart Agro-Max is a fully automatic fertigation control system that ensures the precise mixing and distribution of macro and micro-nutrients (nitrogen, phosphorus, potassium, calcium, magnesium, and trace elements). It digitizes plant nutrition processes in vegetable and fruit greenhouses, hydroponic systems, and orchards.

Smart Agro-Max Advantages in Different Production Systems

In Tomato, Pepper, and Cucumber Greenhouses:

• Precise Nutrient Management: Protects vegetative and generative balance by applying different nutrient recipes.
• Fruit Quality Improvement: Increases fruit firmness, shelf life, and BRIX values with optimum EC and pH control.
• Yield Increase: Provides up to 40% yield increase per square meter with a balanced feeding program.

In Hydroponic and Soilless Agriculture Systems:

• Full Automatic Nutrient Solution Control: Ensures optimum nutrient uptake by continuously monitoring EC, pH, and temperature.
• Closed Circuit System Management: Automatically adjusts the new nutrient solution by analyzing the nutrient concentration in the drainage water.
• Root Zone Optimization: Promotes root development and reduces disease risk.

In Orchards and Open Field Agriculture:

• Drip Irrigation Integration: Delivers nutrients directly to the root zone, working in full compatibility with drip irrigation systems.
• Seasonal Feeding Programs: Applies automatic programs for flowering, fruit set, and post-harvest periods.
• Water and Fertilizer Savings: Provides up to 30% water and 25% fertilizer savings.

Economic Contributions to Farming

Increased Yield and Quality: Professional tomato greenhouses using Smart Agro-Max have observed a 30-40% increase in yield and a 25% increase in export-quality product rates.

Reduction in Fertilizer Costs: Real-time sensor data prevents fertilizer waste, reducing costs by 20-25%.

Labor Efficiency: The automatic control system eliminates manual fertilization, reducing labor costs and human error.

Technical Specifications and Components

• Smart Fertigation Control: Connection for up to 4 different fertilizer tanks.
• Proportional Fertilization: Precise formulation management for each fertilizer.
• High Capacity: 4000 liters/hour capacity for large-scale operations.
• Wireless Communication: Remote control via GSM, WiFi, and LoRaWAN.
• Uninterrupted Operation: Rechargeable battery support for energy cuts.
• Durable Design: IP65 waterproof structure for harsh environments.

Integration into the Esular Smart Agriculture Ecosystem

Smart Agro-Max works in full compatibility with Esular's wireless smart irrigation ecosystem, allowing you to establish a coordinated system with soil moisture monitoring and weather sensors.

Technical Specifications

Hydraulic and Connection Features:

• Inlet/Outlet Connection Diameter: DN65 (2 1/2″)
• Maximum Inlet Flow: 36 m³/h
• Operating Pressure: 8 bar (Max 12 bar)
• Maximum Fertilization Rate: 4000 liters/hour
• Fertilizer Inlets: 3+1, 4 inlets
• Fertilizer Inlet Diameter: DN20 (1″)

Measurement Features:

• pH Range: 0 – 14 pH (Accuracy: ± 0.1 pH)
• EC Range: 0.00 – 19.99 mS/cm (Accuracy: ±2% F.S)
• Temperature Compensation: Available
• Response Time: 20s for EC, ≤ 1min for pH

General System Features:

• Operating Temperature: 0~+65 ℃
• Battery: 3.7 V 5000 mAh rechargeable Li-ion
• Protocols: RS485 and MODBUS integration
• Body: IP65 waterproof durable housing

*Some product features are optional. All features may not be available in a single product at the same time. Please contact Esular experts for detailed information.
