Remote Controlled Wireless Smart Irrigation Central Station - E Series
The biggest problem in agricultural areas is that energy and cabling are costly and impractical. The irrigation management system we developed as Esular is completely wireless. Valve controls and sensor data collection for irrigation are performed entirely wirelessly...
Technical Specifications
| Dimensions | 160 x 240 x 53 - 112 mm |
|---|---|
| Documentation | Technical Documentation Available |
Product description
The biggest problem in agricultural areas is that energy and cabling are costly and impractical. The irrigation management system we developed as Esular is completely wireless. Valve controls and sensor data collection for irrigation are performed entirely wirelessly. Thanks to this system structure, installation is very easy. Simply place the central communication station in a suitable location and easily perform controls.
Wireless Installation
During installation, no cabling is required. other than antenna and solar panel connections. It communicates with valves and sensors via LoRa. It communicates with the cloud server over the GSM infrastructure.
Solar Powered Operation
No external grid connection is required. It operates with a 100-watt solar panel. It has a built-in rechargeable battery and continues to operate for 6 to 12 hours with this battery during power outages, depending on the model. Additionally, it offers up to 2 days of uninterrupted communication with a 14AH battery. If desired, it can be connected to the city grid via an external power input.
Control up to 10 KM
You can read valves and sensors up to 10 km and control them up to 5 km. This allows the entire system to be fully scalable.
Easy Scalability
You can easily add new valves and sensors to the system within 5 minutes. It provides easy addition and removal without the need for reconfiguration.
Wireless Central Irrigation Unit - Electric or Solar Powered - Internet-Based Irrigation Control - Long Range – E Series
The wireless smart irrigation central station can have two different power sources: electric or solar powered. These units can have wireless data collection distances of 5 km point-to-point and 1 km and are equipped with external antennas. They feature GSM and WiFi connectivity, 12-14V DC input, a built-in lithium-ion battery, IP65 protection class, water meter input, manual on-off input, and 4-20 amp pressure sensor input.
These units can have 1 to 4 pump control outputs and can operate for 6 to 12 hours with the built-in lithium-ion battery during power outages. Additionally, they provide support for 32 to 128 valves and sensors, automating irrigation processes. They come with features such as built-in automatic tasks, water meter input, manual on-off input, 4-20 amp pressure sensor input, and pulse inputs.
Due to their affordable price, you can choose between electric or solar-powered, short-range or long-range units. Each unit is waterproof and comes with a 2-year warranty.
Wireless Installation
During installation, no cabling is required other than antenna and solar panel connections. Valves and sensors communicate via LoRa. It communicates with the cloud server over the GSM infrastructure.
Solar Powered Operation
No external grid connection is required. It operates with a 100 Watt solar panel. It has a built-in rechargeable battery and, depending on the model, continues to operate for 6 to 12 hours with this battery during any power outage. Additionally, it offers up to 2 days of uninterrupted communication with a 14AH battery. If desired, it can be connected to the city grid via an external power input.
Control up to 10 KM
You can read valves and sensors up to 10 km and control them up to 5 km. This allows the entire system to be fully scalable.
Easy Scalability
You can easily add new valves and sensors to the system within 5 minutes. It provides easy addition and removal without the need for reconfiguration.
General Specifications:
- The wireless central irrigation unit can be powered by electricity or solar energy.
- It includes a 10 km wireless data collector and an external antenna.
- Thanks to its built-in lithium-ion battery, it can operate for 12 hours during power outages.
- The unit can be controlled via GSM, Wi-Fi, and the internet.
- It has a 12-24V DC input.
- It features 4 pump control outputs, 2 water meter inputs, and 2 4-20 amp pressure sensor inputs.
- It can generate alerts and send SMS notifications in situations such as overpressure or power outages.
- It supports up to 128 valves and sensors and allows adding up to 64 in-device automatic tasks.
- External antenna and accessories are included in the price.
Application Areas
- Smart Agriculture Applications
- Smart Greenhouse Applications
- Smart Landscape Applications
- Vertical Farming Applications
- Smart Irrigation Systems
- Soilless Farming Applications
- SCADA Systems
- IoT (Internet of Things)
- Park, Garden Smart Irrigation Solutions
- LoRa / LoRaWAN Sensor Applications
- Germination, Rooting Automation
Technical Documents
Download the documents for detailed product information
