Wireless Battery-powered CO2-Humidity-Temperature Sensor-Smart Series

Wireless Battery-powered CO2-Humidity-Temperature Sensor-Smart Series - Professional Greenhouse and Livestock Solution

• Wireless communication technology developed for greenhouse, agriculture, and livestock facilities
• Measurement data can be transmitted wirelessly up to 10 km using LoRa technology. Thanks to two-way communication, it offers both data transfer and remote configuration capabilities.
• Continuous operation with solar energy-supported battery technology
• Operates with a fully rechargeable battery system for CO2, humidity, and temperature measurements. Offers long-lasting performance with 3.6 Volt lithium-ion battery technology.
• Professional NDIR CO2 sensor technology
• Measures ambient carbon dioxide, humidity, and temperature values precisely with 1 integrated sensor. Monitors critical parameters for plant growth and animal health in a single device.
• Easy installation and expandable system architecture
• Thanks to its wiring-free structure and plug-and-play feature, it easily integrates into existing greenhouse and livestock facilities and can be expanded as needed.
• Durable design for harsh environmental conditions
• Reliable operation in open areas and high-humidity environments with an IP65 standard water and dust-proof body. Sensitive sensor protection thanks to a special filtered air intake.

Technical Specifications and Advantages:

• Precisely measures carbon dioxide, humidity, and temperature values in greenhouse, poultry house, and barn environments to ensure optimal conditions for plant and animal production.
• Reliable measurement in all climate conditions with a wide operating temperature range between -40°C and +85°C.
• Professional measurement solution manufactured to industrial standards.
• Remote monitoring and setting update capability with LoRa-LoRaWAN wireless communication protocol.
• Years of continuous operation capacity with 6V 110mA Li-SOCl2 battery technology.
• Simultaneous measurement at different points with 2 external humidity-temperature probe connections.
• Integration with alarm and automation systems via 1 dry contact signal output.
• Connection to industrial control systems with RS485 output and MODBUS communication protocol support.
• Completely independent operation without an external power supply.
• Integration with IoT platforms by operating in LoRaWAN APP mode.
• Use of an alternative power source with external power input if needed.
• Easy to use with automatic data collection and transmission modes.
• Full protection against water and dust with professional IP65 protection class.
• Sensor protection is ensured by a specially designed air filter, while the necessary air intake for precise measurement is maintained.
• Provides regular data flow by measuring carbon dioxide, humidity, and temperature at 5-minute intervals.
• Optional external wired IP65 sensor probe for remote point measurement.
• Suitable for various needs with display and display-less model options.
• Easy on-site manual reading in LCD display models.

Product features may vary depending on configuration. All features may not be present in a single product simultaneously.

Precise Humidity and Temperature Measurement Capacity:

• Humidity measurement range: Measurement in the 0% - 100% RH range with a high-precision sensor
• Humidity measurement accuracy: ±2% RH accuracy (at 25°C), which is critically important in greenhouse and poultry house environments
• Temperature measurement range: Wide-spectrum measurement capacity between -40°C and +125°C
• Temperature measurement accuracy: ±0.2°C accuracy (in the 0°C-90°C range), which is vital for plant health

Professional Carbon Dioxide (CO2) Measurement Technology:

• Long-lasting and stable performance with NDIR (Non-Dispersive Infrared) CO2 Measurement Technology
• CO2 measurement range: Precise measurement capacity between 400 ppm – 10,000 ppm, ideal for greenhouse management
• CO2 measurement accuracy: ±(30 ppm + 3%) accuracy, compliant with professional greenhouse standards
• Repeatability: ±10 ppm repeatability value for reliable results
• Fast response time: 20-second response time, instantly detecting changing environmental conditions

Agricultural, Greenhouse, and Livestock Application Areas

• Ideal air quality monitoring for animal health in modern poultry house systems
• Optimum CO2 level control for plant growth in professional greenhouse cultivation
• Environmental condition management for increased yield in smart agriculture applications
• Greenhouse automation and climate control systems integration
• Precise plant care in landscaping and gardening applications
• Ideal growing environment control in vertical farming systems
• Automatic irrigation based on humidity values with smart irrigation systems
• Nutrient solution and environmental condition management in soilless farming applications
• Integrated agricultural production management with industrial SCADA systems
• IoT (Internet of Things) based smart farm systems
• Professional landscape and park-garden management
• Installation of LoRa/LoRaWAN protocol-supported wireless sensor networks
• Precise environmental control in seedling production and germination processes
• Air quality monitoring in enclosed animal shelters such as barns and poultry houses
