Wireless Battery-Powered pH-EC-Temperature Sensor - Smart Series

Package Contents:

• PH sensor probe x1
• EC Sensor probe x1
• PH and EC sensor control unit  x1
• Adapter x1

Wireless Battery-Powered pH-EC-Temperature Sensor - Smart Series

• Wireless Communication
• Measurement data is transmitted wirelessly. It is possible to transmit data up to 10 km. It provides two-way or one-way communication.
• Rechargeable battery operation, with rechargeable battery option
• Can operate entirely with an internal battery for pH and EC measurement.
• pH, EC, and temperature measurement
• It has 1 pH, 1 EC, and 1 temperature sensor probe input.
• Features replaceable probes.
• Internet access with central station, multi-point measurement capability
• Easy scalability
• Thanks to its wireless design, no wiring requirement, and easy installation, you can easily add new sensors to your automation system and expand it.
• It has an IP65 fully waterproof structure.

General Features:

• Measures pH and EC values of dissolved mixtures in water. Also performs water temperature measurement.
• 0~+85 ℃ operating temperature.
• Industrial solution.
• Wireless reading and  updating settings via LoRa-LoRaWAN.
• 3.7 V 5000 mAh rechargeable Li-ion battery
• Has 2 external pH-EC probe connection outputs.
• Has 1 dry contact signal output (optional).
• Has RS485 output and MODBUS communication feature (optional).
• Offers up to 3 years of battery life with low power consumption and sleep mode features.
• Can measure and send data for up to 7 days with the battery.
• Operates in LoRaWAN APP mode.
• External power input feature.
• Automatic operating modes.
• It has an IP65 waterproof structure.
• Thanks to easily replaceable external probe connections, you can easily change the probes.
• Screened and screenless options are available.
• Manual visual reading can be done on screened models.

Some product features are optional. Not all features may be available in a single product simultaneously. Please inquire for details.

pH Measurement Specifications:

• Measurement Range: 0 – 14 pH
• Measurement Temperature: 0 – 60 ℃
• Accuracy: ± 0.1pH (25 ℃)
• Response Time: ≤ 1min
• BNC Connector pH Sensor
• Replaceable probe, Probe life between 6-12 Months
• Operating pressure 2bar, 3 bar(max)

EC Measurement Specifications:

• Measurement range : EC  0.00 – 19.99 mS/cm
• Resolution : EC 0.01 mS/cm   pH 0.01
• Accuracy :EC ±2% F.S     .pH ±0.1
• Temperature compensation : yes
• Replaceable probe, Probe life between 12-24 Months
• Response Time: 20 s
• Operating pressure 4 bar, 6 bar(max)

Temperature Measurement Specifications:

• Temperature measurement range: -40 ~ 125 C
• Temperature measurement accuracy: ±0.2℃@0℃~90℃ (Typical)
• Temperature measurement technique: NTC

Application Areas

• Smart Agriculture Applications
• Smart Greenhouse Applications
• Smart Landscape Applications
• Vertical Farming Applications
• Smart Irrigation Systems
• Soilless Cultivation Applications
• SCADA Systems
• IoT (Internet of Things)
• Park, Garden Smart Irrigation Solutions
• LoRa / LoRaWAN Sensor Applications
• Germination, Rooting Automation
