Wireless Laser Liquid and Solid Level Sensor
Experience the Esular difference for precise level measurement in silos and tanks! With DToF LiDAR technology, wireless data transmission, and a measurement range of up to 40 meters, it operates with ±5cm accuracy even in challenging conditions. Forget traditional level measurement methods! This wireless laser sensor developed by Esular, ...
Technical Specifications
| Size | 285 x 90 x 60 mm |
|---|
Documents
Product description
Experience the Esular difference for precise level measurement in silos and tanks! With DToF LiDAR technology, wireless data transmission, and a measurement range of up to 40 meters, it operates with ±5cm accuracy even in challenging conditions. Forget traditional level measurement methods! This wireless laser sensor developed by Esular can perform precise measurements even in dusty or steamy environments, thanks to LiDAR technology using the Direct Time-of-Flight (DToF) principle.
Wireless Laser Liquid and Solid Level Sensor Features
- High-Precision DToF LiDAR Technology - Flawless performance in silos of all sizes with a wide measurement range from 0.05 to 40 meters.
- Precision exceeding industrial standards with ±5cm measurement accuracy and 1.5cm resolution.
- Ability to operate even in bright sunlight with 100klux ambient light immunity.
- Ability to accurately detect target material with a 0.17° laser emission angle.
- Accurate results even in narrow and deep tanks with single-point precise measurement.
- Reliable and Long-Range Wireless Communication - Seamless data transmission up to 10 kilometers with LoRa-LoRaWAN.
- Easy integration even in challenging environments with its no-wiring design.
- Remote adjustment and control with a bidirectional communication protocol.
- Solar-Powered and Long-Life Battery Technology - Continuous energy source with a self-charging solar panel.
- Long-life Li-SOCl2 battery technology with 5000 mAh capacity.
- Battery life of up to 5+ years in the absence of sunlight.
- Energy saving with low-power sleep mode.
- Durable battery structure capable of operating between -40°C and +85°C.
Technical Specifications
- Measurement Technology: Direct Time-of-Flight (DToF) LiDAR
- Measurement Range: 0.05~40m (90% internal and external reflection), 0.05~12m (10% internal and external reflection)
- Measurement Accuracy: ±5cm
- Resolution: 1.5 cm
- Measurement Frequency: Adjustable between 1 and 2000Hz (default 100Hz)
- Communication Interface: UART
- Wireless Communication: LoRa-LoRaWAN (EU868Mhz)
- Wireless Communication Range: Up to 5 km (in open field)
- Wavelength: 905nm
- Laser Emission Angle: 0.17°
- Reception Field of View: 2.2°
- Ambient Light Immunity: 100klux
- Operating Voltage: 5V
- Power Consumption: 130mA@5V
- Battery Type: 3.6V Li-SOCl2, 5000 mAh
- Solar Panel: Integrated, rechargeable
- Operating Temperature: -40°C ~ +85°C
- Protection Class: IP65 (dust and water resistant)
- Weight: 285g (including wireless module)
Application Areas
- Grain and Feed Silos
- Cement and Powder Material Silos
- Water and Liquid Storage Tanks
- Chemical Material Tanks
- Industrial Process Tanks
- Plastic Raw Material Silos
- Mining Applications
- Food Processing Facilities
- Wastewater Treatment Plants
* For different level measurements, please contact us!
